Highlights:
160 Mbps capacity
50,000 PPS
4.780 – 6.100 GHz support
High output power 29 dBm radio
Integrated 18 dBi directional panel antenna
Powerful OS
iPoll 2 - enhanced communication protocol
Weather proof (IP-66 rated) design
Free NMS (Infinity Controller)
Wall and pole mounting option
Grounding option on the enclosure
Name | Size | Type | |
---|---|---|---|
Documentation
APC 5M -18 datasheet |
583KB | APC | Download |
Documentation
Lepanto mining case study |
992KB | APC | Download |
Documentation
APC series product overview |
3.44MB | APC | Download |
Documentation
APC series user guide |
2.22MB | APC | Download |
Documentation
APC 5M-18 QIG |
580KB | APC | Download |
iPoll 2 uses a centralized control manner, where base station polls every subscriber station (CPE) and ensures smooth packet transmission for voice, video and data.The polling method is smart: stations having data are polled more often versus idle ones.
The APC OS combines wireless technology with quality of service for multiple flows like voice, video and data. QoS on iPoll 2 uses the strict policy method and ensures the lowest latency as well as minimal jitter for the most sensitive real time applications.
